Valor L1 See-Thru Linear Gas Fireplace, Natural Gas

The Valor L1 See-Thru puts one fire between two spaces. It has the same widescreen proportions as the L1, with a 40 inch by 14-1/2 inch view on each side, so two separate spaces can share the same flame. Valor calls it a seamless transition between architectural spaces.

This listing is the natural gas engine. It runs on battery power as a heater, so it doesn't depend on household electricity, and the included Valor 10 remote has a thermostatic mode. Because both faces show, you'll need two fronts to finish the installation, along with a fuel bed and liner.

What Makes the L1 See-Thru Different

• Fire on both sides. The See-Thru has glass on both faces, so two rooms share one fire. Valor describes it as a way to provide zone heating in two separate spaces.
• Runs on batteries. Like all Valor gas fireplaces, it uses four AA batteries as its primary power and works as a heater without household electricity.
• HeatShift option. HeatShift is Valor's fanless convection system for moving warm air away from the opening. Valor recommends it, and it's required with the 1530CIK clean install front.
• Thermostatic remote included. The Valor 10 remote can measure the room and adjust the flame height to hold the temperature you set.

This listing is the Valor 1600KN L1 See-Thru Linear engine (2-sided) for natural gas. The fuel bed, liner, and two fronts are ordered separately.

Key Specifications

• Viewing area: 40 in W x 14-1/2 in H (580 sq in) on each side
• Natural gas input: 19,000 to 30,000 BTU/hr
• Maximum output (Valor): 22,116 BTU/hr
• EnerGuide efficiency (CSA P.4.1-15): 69%
• Venting: 4 in x 6-5/8 in co-axial direct vent, top outlet, field-convertible to rear; co-linear conversion available
• Power: Runs on battery power as a heater, no household electricity needed
• Remote: Valor 10 remote with thermostatic mode, included
• HeatShift: Recommended; required with the 1530CIK clean install front
• Circulating fan: Not offered for this model
• Fronts: Two fronts required per installation
• App control: Optional, needs the GV60WiFi WiFi upgrade kit
• Included with engine: Owner and installation manuals, Valor 10 remote and wall holder, AA and AAA batteries, RBWSK wall switch kit
• Sold separately: Fuel bed, liner, and two fronts

Valor supplies the input, output, and efficiency ratings. How each room feels depends on the spaces, your home's layout, the installation, and how you use the fireplace.

Ownership & Maintenance

The L1 See-Thru uses four AA batteries as its main power source, so keep a spare set handy. Hearth Doctor customers get support after the sale.

A see-through fireplace takes some planning on both sides of the wall. Stop by our Auburn, Brunswick, and Yarmouth showrooms and we'll help with framing, venting, fronts, clearances, and installation.
